Tricone Rock Bit
Created with Pixso.

Water Bit Drilling Bit / HDD Pilot Bit 311.2mm FA517G API-7-1 Standard

Water Bit Drilling Bit / HDD Pilot Bit 311.2mm FA517G API-7-1 Standard

ชื่อแบรนด์: FLRT
เลขรุ่น: 12 1/4 FA517G
MOQ: 20PCS
ความสามารถในการจําหน่าย: 300 ชิ้นต่อหนึ่งในสี่
ข้อมูลรายละเอียด
สถานที่กำเนิด:
จีน
ได้รับการรับรอง:
API-7-1, ISO 9001:2008
ประเภทแบริ่ง:
แบริ่งแรงเสียดทานที่ปิดสนิท
วัสดุตัด:
ทีซีไอ
มาตรฐาน:
API-7-1, ISO 9001:2008
ชุด:
เอฟเอ
กปปส:
517
คุณสมบัติเสริม:
G : การป้องกันมาตรวัดเสริมแรง
ใบสมัคร 1:
การเจาะ HDD (Pilot Bit)
ใบสมัคร 2:
การขุดเจาะบ่อน้ำมันตื้น
รายละเอียดการบรรจุ:
กล่องไม้อัด / กล่องเหล็ก
เน้น:

ดอกสว่านเจาะฮาร์ดร็อค FA517G

,

HDD Pilot Bit 311.2mm

,

ดอกเจาะบ่อน้ำ API-7-1

คำอธิบายผลิตภัณฑ์

311.2mm FA517G , Rock Bit, Water Well Drilling Bit , TCI Bit, Rotary Drilling Bit , HDD Pilot Bit

RECOMMENDED DRILLING PARAMETERS FOR APPLICATION

Types & IADC Code

417

437

447

517

527

517

527

537

547

617

627

637

WOB

KN/mm(Bit Dia.)

0.4~0.9

0.4~0.9

0.35~1.0

0.35~1.0

0.5~1.0

0.6~1.1

0.7~1.2

Lb/in. (Bit Dia.)

2285~5142

2285~5142

2000~5714

2000~5714

2857~5714

3428~6285

4000~6857

Rotation Speed (Rpm)

140~60

240~70

125~50

~60

110~50

100~40

80~4

Cone offset

  1. - It forces the cone to rotate around the axis of the bit
  2. - The cone slips as it rotates causing tearing and gouging action
  3. - Amount of offset directly relates to the strength of drilled rock
  4. - Large offset used for soft formation
  5. - Hard brittle rock need no offset
  6. - Medium hard rock need up to 2 offset
  7. - The degree of offset is defined as the horizontal distance between the axis of the bit and a vertical plane through the axis of the journal
